Start with the fieldwork question

A longitudinal survey observes some units more than once. A rotating panel replaces part of the sample at regular intervals, so it can support both cross-sectional estimates and estimates of change.

This article follows one small design from planning to selection. Each cohort is interviewed twice. At a steady state, half of one occasion’s issued sample also appears at the next occasion. The example is deliberately simple and avoids permanent random numbers, unequal-probability sampling, and a choice of longitudinal variance estimator until the basic workflow is clear.

Two packages have different jobs here. svyplan converts precision, response, retention, and overlap assumptions into fieldwork numbers. samplyr selects the start-up and refreshment samples and records which panels are active.

Choose the kind of repeated survey

These common designs should not be treated as interchangeable (Smith, Lynn, and Elliot 2009; Lynn 2012).

Design	What happens	Basic implementation
Fixed panel	One sample is interviewed repeatedly	Run `execute()` once and join later responses to the selected units
Fixed panel with entrants	The original panel is kept and new population entrants are added	Draw the original sample and each entrant cohort separately
Repeated cross-section	A fresh population sample is drawn on every occasion	Reuse the design with a new frame and seed
Rotating panel	Several cohorts are live and one is replaced regularly	Use a start-up partition, then draw one refreshment cohort per occasion
Split panel	A continuing panel and a fresh cross-section run together	Keep the two samples and their estimators distinct

Before choosing among them, state the target population. A fixed wave-1 population cannot represent later births. A cross-sectional target at each occasion needs refreshed frame coverage. samplyr cannot infer that choice from the data.

Plan a two-occasion rotation

design_overlap() describes the time a cohort spends in and out of sample. The string "2" means that a cohort is interviewed on two consecutive occasions and then leaves.

library(svyplan)
overlap_plan <- design_overlap("2")
overlap_plan[1]
#> [1] 0.5
plot(overlap_plan, type = "schedule", start = "immediate")

Rotation chart for cohorts interviewed on two consecutive occasions.

This is issued-sample overlap. Below full response, the overlap among respondents may differ because response can persist across occasions.

Next, define the responding sample needed for a proportion and allow for response at recruitment and retention into the second interview.

precision_target <- n_prop(p = 0.5, moe = 0.08)

panel_plan <- n_panel(
  precision_target,
  retention = 0.90,
  resp_rate = 0.80,
  design = "rotating",
  start = "immediate"
)

panel_plan
#> Panel recruitment (rotating, 2-wave life)
#> entrants: 99 per occasion -> 150 responding, pooled over 2 cohorts, short of the 151 the target needs
#> proportion (wald): se = 0.04082, moe = 0.08, cv = 0.0816
#>
#>  wave retention n_resp se      moe
#>  1              79     0.05626 0.1103
#>  2    0.9       71     0.05931 0.1162
#>
#> # summary() for the launch, the loss and per-wave cv

fieldwork_plan <- design_schedule(
  panel_plan,
  overlap_plan,
  horizon = 3,
  horizon_policy = "continuing",
  refreshment = "entrant_register",
  rounding = "ceiling"
)

The two numbers needed for selection are explicit in the result.

intake_n <- ceiling(panel_plan$n_entrants)

selection_sizes <- c(
  startup = panel_plan$n_cohorts * intake_n,
  intake_each_occasion = intake_n
)
selection_sizes
#>              startup intake_each_occasion
#>                  198                   99

startup is the number issued across the two cohorts present at the first occasion. intake_each_occasion is the fresh cohort added later. They are not two names for the same sample size.

n_panel() uses the response and retention rates supplied by the planner. It does not estimate attrition, adjust weights for nonresponse, or guarantee that every realized occasion reaches the target. Its optional assurance argument can add a probability-of-reaching-target calculation when that is needed.

Draw and partition the start-up sample

The immediate start contains two panels recruited together at occasion 1, and both are then at their first interview. One panel is recruited into a two-interview life and is active on occasions 1 and 2. The other is recruited into a one-interview life and is active only on occasion 1. They differ in life length, not in how far they have already progressed through the retention chain.

library(dplyr)
data(ken_enterprises)

base_design <- sampling_design() |>
  draw(n = selection_sizes[["startup"]])

startup <- execute(
  base_design,
  ken_enterprises,
  seed = 7,
  panels = fieldwork_plan
)

count(startup, .panel)
#> # A tibble: 2 × 2
#>   .panel     n
#>    <int> <int>
#> 1      1    99
#> 2      2    99

Passing the plan here lets samplyr extract the startup panels and freeze their full activity schedule when the sample is drawn. The partition does not draw future entrants or create later frame vintages. It only organizes this one executed sample.

Materialize an occasion from the recorded schedule with execute(wave = ).

startup_wave_1 <- execute(startup, wave = 1)
startup_wave_2 <- execute(startup, wave = 2)

c(
  wave_1 = nrow(startup_wave_1),
  wave_2 = nrow(startup_wave_2)
)
#> wave_1 wave_2
#>    198     99

Wave activation is a probability subsample, not a row filter. The resulting object carries an activation factor in its weight and can be exported as a two-phase survey design.

class(as_svydesign(startup_wave_2))
#> [1] "twophase2"     "survey.design"

Certainty units and permanent small pools do not follow the overlap declared by this automatic route, so it refuses them. They can still use an explicit data-frame panel schedule when their operational and inference treatment has been decided. Unequal-probability and multistage designs also need care in variance estimation. as_svydesign() refuses unsupported combinations rather than silently replacing their variance estimator.

Add a refreshment cohort

At occasion 2, the older start-up cohort has left and a fresh cohort enters. For a dynamic population, that cohort should be drawn from the frame vintage and eligibility definition specified by the survey design.

The synthetic example below creates a separate entrant register. Its distinct identifiers make the cohort frames disjoint by construction.

set.seed(99)

entrants <- ken_enterprises |>
  slice_sample(n = 500, replace = TRUE) |>
  mutate(
    enterprise_id = paste0("NEW_", sprintf("%04d", row_number()))
  )

intake_design <- sampling_design() |>
  draw(n = selection_sizes[["intake_each_occasion"]])

intake_2 <- execute(intake_design, entrants, seed = 8)

rotation_program() records how separately executed cohorts fit into one fieldwork programme.

program <- rotation_program(
  cohorts = list(startup = startup, intake_2 = intake_2),
  schedule = fieldwork_plan,
  through = 2
)

occasion_2 <- execute(program, wave = 2)
occasion_2
#> ── Rotation Wave 2 ─────────────────────────────────────────────────────────────
#>
#> • startup: 99 rows, panel 1
#> • intake_2: 99 rows, panel 1
#> ℹ Weights are valid within a cohort and are not combined.

The result is a collection with one component per live cohort. It is not automatically row-bound and its weights are not combined. The correct combined estimator depends on who was eligible for each cohort. Disjoint entrant frames are simpler. Refreshment draws from the whole population can give a unit more than one chance of selection and require a union-probability or multiple-frame estimator.

For a longer run, increase horizon when creating fieldwork_plan, repeat the intake step once per occasion, and register the cohorts through the latest fielded occasion. The planned value panel_plan$n_entrants is the steady-state intake for each draw.

Check overlap in an executed master

svyplan::design_overlap() reports overlap from the planned schedule. samplyr::joint_expectation() reports what an executed master records, including block-size remainders. For manually scheduled designs, it also handles permanent certainty units.

executed_overlap <- joint_expectation(startup, waves = c(1, 2))

c(
  planned = overlap_plan[1],
  executed = sum(executed_overlap$take_both) / sum(executed_overlap$take_1))
#>  planned executed
#>      0.5      0.5

Be explicit about the denominator when wave sizes differ. Also say whether the overlap counts issued units or respondents. samplyr knows the first, but response data are needed for the second.

Attach responses without changing the design

A tbl_sample records selection. Later responses can be joined one-to-one by a stable unit identifier while the sample remains one row per selected unit. Duplicating a selected row once per interview and exporting that long table as a new survey design would count the unit as though it had been sampled more than once.

For two waves derived from the same master, stack_waves() checks their common origin and returns a long table for a longitudinal analysis package.

wave_table <- stack_waves(startup_wave_1, startup_wave_2)
names(wave_table)[1:4]
#> [1] "wave"          "master_id"     "panel"         "design_weight"

design_weight is the design weight, including activation. It is not a final nonresponse-adjusted or calibrated weight. master_id links the same selected unit across these waves. It is not a cluster identifier.

Two separate cross-sectional variance estimates do not contain the covariance needed for a variance of change. The appropriate longitudinal estimator depends on the design, response process, calibration, and available joint inclusion information. stack_waves() validates the handoff but deliberately does not choose that estimator.

Where PRNs fit

Permanent random numbers control overlap between separate draws. Panel schedules control how long an already selected cohort remains active. A survey may use both, but neither substitutes for the other. Start with this article when the fieldwork rule is “keep each cohort for two occasions.” Use vignette("sampling-coordination") when the rule is “make the next draw share more or fewer units with the current draw.”

Limits to decide before fieldwork

State whether estimates refer to the wave-1 population, units present at every occasion, or the population at each occasion.
Keep wave-1 strata fixed for a fixed panel. Re-executing a design against a new frame instead reclassifies units using that frame.
Decide whether the sampled unit is also the followed unit. For example, rotating addresses while areas remain fixed has different longitudinal properties from rotating whole areas.
Verify entrant coverage and identifier continuity in the frame. A sampling function cannot establish either one.
Plan nonresponse adjustment, calibration, attrition treatment, and the variance of change in the analysis layer.

The short workflow

Use design_overlap() to describe the cohort life.
Use n_panel() to obtain n_in_sample and n_entrants.
Draw the start-up sample and partition it with panels.
Materialize scheduled occasions with execute(wave = ).
Draw each refreshment cohort against its intended frame vintage.
Register the cohorts with rotation_program().
Export components with their own designs and use a longitudinal inference method suited to the survey.

References

Lynn, Peter. 2012. “Longitudinal Survey Methods for the Household Finances and Consumption Survey.” Report prepared for the {European Central Bank} V2.1. Institute for Social; Economic Research, University of Essex.

Smith, Paul, Peter Lynn, and Dave Elliot. 2009. “Sample Design for Longitudinal Surveys.” In Methodology of Longitudinal Surveys, edited by Peter Lynn, 21–33. Chichester: John Wiley & Sons.
